16 Pin Flat Ribbon Cable
16 pin lDC ribbon cables' characteristics make the cable stand out to be used in extremely limited spaces. The cable's applications will differ from cylindrical cables and do not require additional wire harnesses to organize the cables. The insulation material is properly joined to form a ribbon-like appearance.
This ribbon cable has copper conductors- Copper is preferred for its high conductivity level due to its low resistivity. This makes the 16 connector flat ribbon cable efficient in the transmission of power.
The cable has insulation commonly made of Polyvinyl Chloride, which offers efficient conductors protection. PVC has a high-temperature range (-40- 1050 °C). This significantly prevents the ribbon cable from harsh weather conditions.
- Evershine
- Fujian, China
- 7-15days
- Information
16 Pin Flat Ribbon Cable
OEM ODM wiring Harness Factory
Customized Male to Female Wire Harness
Terminal wire 1.25 air docking Cable Harness
Terminal Wire Harness Kit manufacturer
Custom Cable Assembly
The lDC connector flat ribbon cable is a ribbon cable with a 16 pin lDC connector.
The 16 pin lDC connector flat ribbon cable is used for household appliances, electrical devices, DlY breadboards, and power supplies, among others.
A 16 pin female connector flat ribbon cable has copperconductors-Copper is preferred for its high conductivity level due to its low resistivity. This makes the cable efficient in the transmission of power.
1.27MM,2MM, 2.54MM pin connector
16 pin flat ribbon cable connector
LOW MOQ 50pcs accepted
The prototype is available, lead time: 1-3 days
16 Pin Ribbon Cable Overview
Over the years, the wiring industry has undergone different changes with each change, trying to make the cable application more efficient.
Owing to this development, the 16 pin flat ribbon cable has also not been left out. This unique cable features 16 pins with a cable that resembles a ribbon piece. it can easily be defined as a ribbon cable that comes with a flat but rectangular design. The main purpose of the 16 pin flat ribbon cable is mass termination when it comes to insulation-displacement contact connectors.
A UL-certified 16 ribbon cable is manufactured of durable and high-quality material, easily flexible, and easy to use. It's a common ribbon cable used on electrical equipment, DlY breadboard, power supply, and home appliances. With this in mind let's delve in and have a better understanding of a16 pin ribbon cable.
Features of 16 Pin Flat Ribbon Cable
Just like other ribbon cables, a 16-pin flat ribbon cable resembles a ribbon with greyinsulation and a red stripe at one edge. This is a common feature, but to differentiate itfrom other flat ribbon cables, it has a UL rating of UL 2651. You can always check on thecable since, after certification, the manufacturer is mandated to have the UL ratingprinted on the ribbon cable. Other features include;
The cable has a terminal pitch of 1.27mm,2.0mm, 2.54mm
Has 16 pins and two rows
Voltage and current rating of 250V and 1A, respectively
The maximum contact resistance of 30mOhm
Most 16-pin flat ribbon cables are custom long
Advantages of 16 Way Ribbon Cable
16 pin lDC ribbon cables' characteristics make the cable stand out to be used in extremely limited spaces. The cable's applications will differ from cylindrical cables and do not require additional wire harnesses to organize the cables. The insulation material is properly joined to form a ribbon-like appearance.
This ribbon cable has copper conductors- Copper is preferred for its high conductivity level due to its low resistivity. This makes the 16 connector flat ribbon cable efficient in the transmission of power.
The cable has insulation commonly made of Polyvinyl Chloride, which offers efficient conductors protection. PVC has a high-temperature range (-40- 1050 °C). This significantly prevents the ribbon cable from harsh weather conditions.
Also, the insulation separates the conductors, preventing them from any contact. Therefore, there is no likelihood of any circuit interference.
16 pin lDC ribbon cable is flexible and durable- You can fold the cable with ease. This allows you to position it in any way to have space for other cables within a device. Also, a UL-certified ribbon cable will serve you for a longer period.
Applications of 16 Pin lDC Ribbon Cable
A 16 pin lDC connector flat ribbon cable is a new high-quality type of flat ribbon cable with an easy connection and operation with its special interface. lt can bend or fold easily, making its application possible in household appliances, electrical devices, DIY breadboards and power supplies,among others
Now, you have some information about a 16 pin lDC connector ribbon cable which can help you differentiate it from other types of ribbon cables. lt's among the latest ribbon cables on the market, but it's easy to change or install another. However, depending on the complexity of the device, consider engaging an expert to offer a helping hand.
